000 -06 Reserved for future use
Table value:
U
U: Flag
Example: 0
Expl.: Reserve
000 -07 Synchronization mode
Table value: S
S: Synchronization flag
0- Synchronization not possible
1- SYNC input active
2- Synchronization via radio clock receiver
Example: 1
Expl.: Synchronization is done via SYNC input
000 -08 Synchronization window surrounding the end of a registration period
Table value: F
F
FF: Length of the synchronization window in seconds
Exception: if the value is 0, synchronization can happen at any time
Example: 0 9
Expl.: Synchronization is possible in a window of
9 seconds at the end of the
registration period
000 -09 Synchronization tolerance: if the synchronization changes the system time by
more than this number of seconds, it will be marked in the device status (this
table address exists for version 1.04.01 and up)
Table value:
T
T
TT: Synchronization tolerance
Note: If the value is 0, synchronization is never marked in the device sta-
tus
Example: 0 2
Expl.: If synchronization changes the system more than 2 seconds, the event
will be marked in the device status.
000 -10 Rate control mode
Table value: T
T:
0- Rates are controlled by control inputs
1- Rates are controlled by the tariff calendar
Example: 0
Expl.: Rates are controlled by control inputs
109 -rr Reset index and corresponding timestamp
rr: requested reset (rr:=00 to 99):
00 last reset
01 second last reset
... and so on
Table value:
n n M M - D D h h : m m
nn: internal reset index (nn:=01 to 12)
MM-DD: Month - Day
hh:mm: hour : minute
Example:
0 1 0 3 - 1 5 1 0 : 0 0
Expl.: The reset with index 01 took place on 15. March at 10:00.
