A 10
1mt -xx Cumulative energy counter reading at the end of the last registration period
(MP1 or MP2)
m: Registration period (m:=0, 1)
0 Registration period MP1
1 Registration period MP2
t: Energy rate (t:=0, 1, 2, 3, 4)
0 Total
1 Energy rate 1
2 Energy rate 2
... etc.
xx: desired value (Counter/Total)
00 Counter 1
01 Counter 2
... etc.
15 Counter 16
64 positive Total 1
65 positive Total 2
66 positive Total 3
67 positive Total 4
80 negative Total 1
81 negative Total 2
82 negative Total 3
83 negative Total 4
Table value: d d d D d d d d
dddddddd: Counter reading
Example: 0 0 0 0 0 0 2 0
Expl.: Counter reading at the end of the last registration period: 20
130 -xx Pulse count for an input
xx: pulse input (xx:= 0 to 15)
00 In1
01 In2
... etc.
Table value: d d d d d d D d d d d
ddddddddddd: Pulse count
Example: 0 0 0 0 0 0 0 0 0 0 4
Expl.: The input has counted 4 pulses.
