A 11
20m
-xx Demand values of the current registration period
m:=0
to
m:=1
m: Registration period (m:=0, 1)
0 Registration period MP1
1 Registration period MP2
xx: desired value (Counter/Total)
00 Counter 1
01 Counter 2
... etc.
15 Counter 16
64 positive Total 1
65 positive Total 2
66 positive Total 3
67 positive Total 4
80 negative Total 1
81 negative Total 2
82 negative Total 3
83 negative Total 4
Table value: d d d d d d d d
dddddddd: demand
Example: 0 0 0 0 0 0 1 2
Expl.: Current demand is 12
20m
-xx Apparent demand of current registration period
m:=3
to
m:=4
m: Registration period (m:=3, 4)
3 Registration period MP1
4 Registration period MP2
xx: Apparent demand value (xx:=0,1)
00 Apparent demand 1
01 Apparent demand 2
Table value: d d d d d d d d
dddddddd: Apparent demand
Example: 0 0 0 0 0 0 1 2
Expl.: The apparent demand is 12
20m
-xx cos(φ) of current registration period
m:=6
to
m:=7
m: Registration period (m:=6, 7)
6 Registration period MP1
7 Registration period MP2
xx: cos(φ) (xx:=0, 1)
00 cos(φ)1
01 cos(φ)2
Table value: S d d d d d d d d
dddddddd: cos(φ)
S = space for positive values‚ „-„ for negative values
Example: 0 0 0 0 1 0 0 0
Expl.: The cos(φ) is 1
