A 22

609 -xx Pulse weighting for totaling units: common divisor of the negative pulse output

xx= 00 for totaling unit 1

xx= 01 for totaling unit 2

…

xx= 03 for totaling unit 4

Table value: N N N N N N N N N N N N

Example: 3

Note: value:=0 → the pulse output is disabled

61y -xx Pulse weighting for totaling units: numerator for inputs

y= Index of the totaling unit

y= 00 for totaling unit 1

y= 01 for totaling unit 2

…

y= 03 for totaling unit 4

xx= Index of the input

xx= 00 for input 1

xx= 01 for input 2

…

xx= 15 for input 16

Table value: Z Z Z Z Z Z Z Z Z Z Z Z

Note: The numerator can have a negative value

620 -xx Analogue inputs: setting values type (from version 1.06.00 and up)

xx: desired value (input)

00 Counter 1

01 Counter 2

... etc.

15 Counter 16

Table value: T

T: 0: instantaneous value (default)

1: average value

Example: 0

Expl.: With instantaneous value
