Baer DLX - Page 131

A 21
600 -04 Balance calculation (yes/no)
Table value: S
S: 0- without balance calculation
1- with balance calculation
Example: 1
Expl.: with balance calculation
600 -05 Number of analogue inputs (from version 1.06.00 and up)
Table value: A
A: Number of analogue inputs
Example: 4
Expl.: The DLX is currently programmed to use 4 analogue inputs.
602 -xx Pulse weighting for energy (numerator)
xx= 00 for pulse input 1
xx= 01 for pulse input 2
…
xx= 15 for pulse input 16
Table value: Z Z Z Z Z Z Z Z Z Z Z Z
Example: 1
603 -xx Pulse weighting for energy (divisor)
xx= 00 for pulse input 1
xx= 01 for pulse input 2
…
xx= 15 for pulse input 16
Table value: N N N N N N N N N N N N
Example: 3
606 -xx Pulse weighting for totaling units: common divisor of the positive register
xx= 00 for totaling unit 1
xx= 01 for totaling unit 2
…
xx= 03 for totaling unit 4
Table value: Z Z Z Z Z Z Z Z Z Z Z Z
Example: 1 0
607 -xx Pulse weighting for totaling units: common divisor of the negative register
xx= 00 for totaling unit 1
xx= 01 for totaling unit 2
…
xx= 03 for totaling unit 4
Table value: Z Z Z Z Z Z Z Z Z Z Z Z
Example: 1 0
608 -xx Pulse weighting for totaling units: common divisor of the positive pulse output
xx= 00 for totaling unit 1
xx= 01 for totaling unit 2
…
xx= 03 for totaling unit 4
Table value: N N N N N N N N N N N N
Example: 3
Note: value:=0 → the pulse output is disabled
