Baer DLX - Page 136

A 26
700 -82 Type and capacity of the successfully activated PC-Card
Table value: t t t t t c c c * B
t t t t t: card type: SRAM or FLASH
c c c: Capacity
*: k for kilobyte; m for Megabyte
Example 1: S R A M 2 5 6 K B
Expl.: The currently inserted and successfully activated card in the DLX is of
type SRAM and has a capacity of 256 kByte.
Example 2: S R A M 0 0 4 M B
Expl.: The last card that was successfully activated in the DLX was of type
SRAM and had a capacity of 4 MByte.
If no card has been successfully activated the DLX will send:
- - - - - - - - - - - -
700 -83 State of the PC-Card in the DLX
Table value: n n
nn: 70-
71-
72-
73-
74-
75-
76-
77-
78-
79-
7A-
7B-
7C-
7D-
No card activated
Card activated but not present
Card activated but write protected.
Card activated, unit busy determining type and capacity
Unit is busy calculating the number of sectors that need to be buffered
during an update of the administration information.
Unit is busy writing administration information to the card.
Unit is busy determining the number of the last DEF file.
Unit is busy formatting the card.
Card is of the wrong type (neither SRAM nor FLASH from AMD)
Capacity of the card is not sufficient
The currently inserted card was activated successfully. All is in
order!
Unit is busy updating the administration information
Unit is busy deactivating the card
The currently inserted card is not the one that was last activated.
700 -84 Date and time of PC-Card activation (from version 1.03.08 up)
Table value: Y Y M M D D Z W h h m m
YYMMDD: Year Month Day
Z: „W“ for CET, „S“ for CEST (summertime)
W: Weekday( 1-Monday, 7-Sunday)
hhmm: hour minute
Example: 0 0 1 2 0 6 W 3 1 5 3 8
Expl.: The PC-Card was activated on Wednesday, 6
th
of December 2000 at
15:38 hours (CET).
701 -00 Registration period length (in minutes)
Table value: D
1
D
1
D
2
D
2
D
2
D
2
D
3
D
3
D
3
D
3
D
1
D
1
Registration period MP1
D
2
D
2
D
2
D
2
Registration period MP2
D
3
D
3
D
3
D
3
Registration period MP3 (not implemented in DLX)
Example: 1 5 0 0 3 0 0 0 0 0
Expl.: Registration period MP1: 15 minutes
Registration period MP2: 30 minutes
