A 31
901 -08 Use device status of a registration period to mark status changes of logic inputs
Table value: Z
Z: Flag
0: Bit0 in the device status of a registration period is always 0
1: Bit0 in the device status of a registration period is set to 1, if the
state of a logic input has changed during that registration period..
Example: 0
Expl.: Bit0 in the device status of a registration period is always 0
901 -09 Device identifier
Table value: D D D D D D D D D D D D D D D D
Device identifier
Example: 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6
Expl.: The device identifier is 1234567890123456.
901 -10 Time and Summertime bit in the device status of the registration period
Table value: S
S: Summertime flag
0: correspond to the state at the end of the registration period (DLX
standard)
1: correspond to the state during the registration period
Example: 0
Expl.: DLX standard
902 -00 Currently active rate (demand, energy, from version 1.04.00 and up)
Table value: E M
E: energy rate
M: demand rate (maximum)
Example: 1 3
Expl.: Energy rate 1, demand rate 3
902 -01 Current reset indices (Cnt12 and Cnt99, from version 1.04.00 and up)
Table value: ct
12
ct
12
ct
99
ct
99
ct
12
ct
12
: external reset index (1 to 12), can be set using DLXPARA
ct
99
ct
99
: internal reset index modulo 100 (0 to 99)
Example: 0 1 1 2
Expl.: 01: current month (e.g. January);
12 resets have occurred since the last unit restart.
902 -02 Position of the program protection switch (from version 1.04.00 and up)
Table value: F
f-Flag:
0: Programming is disabled
1: Programming is enabled
Example: 1
Expl.: Programming is enabled
