B 5
P 20000 ee Min. pulse length at input ee Length:=Display*10 ms;
→see also 10000
P 20100 ee Min. pulse interval at input ee Length:=Display*10 ms;
→see also 10000
P 20200 ee Max. pulse length at input ee,
pulse length monitoring
Length:=Display*10 ms;
0: = pulse length monitor deactivated
→see also 10000
P 20300 ee Input signal inversion 0:=not inverted; 1:=inverted;
→see also10000
P 20400 ee Pulse barrier: before top Length:=Display*100 ms;
→see also 10000
P 20500 ee Pulse barrier: after top Length:=Display*100 ms;
→see also 10000
P 20600 ee Pulse barrier 0:=Off; 1:=On;
→see also10000
P 20700 ee Instantaneous value 0:=Off; 1:=On;
→see also10000
S 21000
21001
21002
21003
ee Assignment to: Total 1
Total 2
Total 3
Total 4
→
ee=01 for input 1;
→Value needs to contain the actual
assignment ratio
→see also 21100
S 21100 pp Assignment to totals : common divi-
sor of the total
→
pp from 01 to 04;
→see also 10100 and 21000
S 22000 ee Analogue inputs: minimum value
from version 1.06.00 and up
→
ee from 01 to 16;
→ee=01 for input In1
→ee=02 for input In2
...
S 22100 ee Analogue inputs: maximum value
from version 1.06.00 and up
→
ee from 01 to 16;
S 22200 ee Analogue inputs: signal type
from version 1.06.00 and up
→
ee from 01 to 16;
0:=4mA..20mA
1:=0mA..20mA
S 22300 ee Analogue inputs: values type (calcu-
lation), from version 1.06.00 and up
→
ee from 01 to16;
0:=instantaneous value
1:=average value
P 28100 pp Output for positive part of the total Hexadecimal bit mask:
0:= no output;
1:=Out1; 2:=Out2; 4:=Out3;
8:=Out4; 16:=Rel1;
32:=Rel2;
→pp from 01 to 04;
→see also 10100
P 28101 nn Output for negative part of the total
→
nn from 01 to 04;
→see 28100
P 28102 mm Output for registration period
→
mm=01 for MP1 (MPA1);
→mm=02 for MP2 (MPA2);
→see also 28100
P 28103 01 Output for maximum demand reset
→
see also 28100
P 28104 aa Output for alarms
→
aa=01 for alarm1;
→aa=02 for alarm2;
→see also 28100
P 28105 tt Output for rates
→
tt from 01 to 04
→tt=01 for rate output TRA1
P 28106 01 Length of the registration period out-
put pulse
length:=display*200 ms;
→value from 1 to 100
P 28107 01 Length of the reset output pulse length:=display*200 ms;
→value from 1 to 100
P 28108 01 Mode of RSTA (reset output) 0:=pulse; 1:=switch
