B 6
P 28109 aa Length of alarm output pulse
→
aa=01 for alarm1;
→aa=02 for alarm2;
→Display in seconds from 1 to 254
P 28110 aa Mode of alarm outputs 0:=pulse; 1:=switch
→aa=01 for alarm1;
→aa=02 for alarm2
P 28111 ll Output assignment for logic outputs
→
ll from 01 to 04
→ll=01 for logic output Log1
→see also 28100
P 28112 ee Output assignment for pulse inputs
→
ee from 01 to 16
→ee=01 for input In1
→ee=02 for input In2
...
→see also 28100
S 28700 cc Active input for calculation of appar-
ent demand and cos (ϕ)
Display:=Z1 to Z16: input 1 to 16
:=S1+ to S4+: pos. total 1 to 4
:=S1- to S4-: neg. total 1 to 4
→cc:=01 for cos
1
(ϕ)
→cc:=02 for cos
2
(ϕ)
S 28701 cc Reactive input for calculation of ap-
parent demand and cos (ϕ)
→
see 28700
P 29000 pp Output pulse for totaling unit: HIGH-
time
Length:=display*10 ms;
→pp from 01 to 04;
→see also 10100
P 29100 pp Output pulse for totaling unit: LOW-
time
Length:=display*10 ms;
→see 29000
P 29200 pp Divisor for totaling unit pulse output
→
pp from 01 to 04;
→see also 10100
P 29300 pp Hysteresis for outputs of totaling units
→
see 29200
P 29400 pp Totaling unit output inversion
→see 29200
S 30000 ee Input pulse weighting: Numerator
→
see 10000
S 30100 ee Input pulse weighting: Divisor
→
see 10000
P 30200 ee Decimals for energy counters Display: 0- no decimals
1- one decimal
2- two decimals
→see also 10000
P 30201 pp Decimals for energy totals
→
see 30200 and 10100
P 30202 ee Decimals for demand counters
→
see 30200
P 30203 pp Decimals for demand totals
→
see 30201
P 30204 cc Decimals for apparent demand
→
cc:=01 for Cos
1
(
ϕ
)
→cc:=02 for Cos
2
(ϕ)
→see 30200
P 31000 01 Number of counters (inputs) Number:=1 to 16
P 02 Number of totaling units Number:=0 to 4
P 03 Separate totals (differential totals) 1:=always active
P 04 Saldo calculation 0:=Off; 1:=On
P 05 Number of energy rates Number:=1 to 4
P 06 Number of demand rates Number:=1 to 4
P 31001 01 Number of apparent demand calcs. Number:=0 to 2
P 31002 01 Number of analogue inputs
from version 1.06.00 and up
Number:=0 to 16
S 64001 01 Reset blockage in registration peri-
ods
Number:=1 to 99
S 64002 01 Time for automatic scolling of the
scroll list (in seconds)
Time:=seconds for automatic scroll-
ing
0:=manual scrolling
S 64003 01 Time window for synchronization:
alarm free
Time:=seconds
S 64004 01 Polarity of SYN input signal 0:=positive (rising) edge
1:=negative (falling) edge
