B 7
S 64005 01 Internal (settable) reset index value:=1 to 12
S 64006 01
Mode of automatic time controlled
reset
0:=Off;
1:=Daily; 2:=Weekly;
3:=Monthly; 4:=Yearly
S 02
Time controlled reset: month
Month:=1 to 12
S 03
Time controlled reset: day
Day:=1 to31
S 04
Time controlled reset: hour
Hour:=0 to 23
S 05
Time controlled reset: minute
Minute:=0 to 59
S 06
Time controlled reset: weekday
0:=Monday .... 5:=Saturday;
6:=Sunday
S 64007 01 Time window for synchronization Time:=seconds
S 64100 01
Input assignment for SYN signal
Hexadecimal bit mask:
0:= function disabled;
1:=Ctl1; 2:=Ctl2; 4:=Ctl3; 8:=Ctl4;
16:=Ctl5; 32:=Ctl6; 64:=Ctl7
S 64101 tt Input assignments for rate control
inputs
→
tt from 01 to 04
→tt=01 for rate input TR1
→see 64100
S 64102 01 Input assignment for RSTX input
→
see 64100
S 64103 ll Input assignments for logic inputs
→
ll from 01 to 04
→ll=01 for logic input Log1
→see 64100
S 64104 01 Assignment for ANZ input
→
see 64100
P 64202 rr Scroll list: address Display:=list of addresses
0:=end of scroll list
→rr from 01 to 40
→rr=01: first entry
S 64300 tt Rate control inputs: demand rate
mask
Display: 0:=Input disabled
1:=Input enabled
→tt from 01 to 04
→tt=01 for rate control input TR1
S 64301 tt Rate control inputs: energy rate mask
→
see 64300
S 64310 kk Rate control combinations for de-
mand
Display:=rate 1 to 4
→kk from 01 to 16;
→kk=01: TR1-4 no rate active
→kk=02: TR1 rate 1 active
→kk=03: TR2 rate 2 active
→kk=04: TR1+TR2 rate 1 & 2 active
...
→kk=16: TR1-4 all rates active
S 64311 kk Rate control combinations for energy
→
see 64310
S 64400 01 Rate control via... 0:=external rate control inputs
1:=internal rate calendar
S 64401 tt Text for demand rate
→
tt from 01 to 04
S 64402 tt Text for energy rate
→
see 64310
