INTRODUCTION
USER QUALIFICATIONS
1 - 2 I-E96-506B1
®
Power Modules
There are two AC power modules: IEPAS02 System Power Mod-
ule and IEPAF02 Field Power Module. The IEPAS02 module
provides +5, +15, -15 and +24 DC voltages. The IEPAF02 mod-
ule provides +24 VDC only for field powered devices.
The IEPAS02 and IEPAF02 modules replace the IEPAS01 and
IEPAF01 modules. Both sets of modules can be used in the
same cabinet. The IEPAS02 and IEPAF02 modules are compat-
ible with the IEPAS01 and IEPAF01 modules.
Power Mounting Units
The IEPMU01 and IEPMU02 Power Mounting Units are
designed to provide housing and power connections to the
power modules. The power mounting units can service up to
ten power modules.
Power mounting units segregrate power modules from process
control modules and are built to handle heavier currents. The
IEPMU01 Power Mounting Unit is a rear mounted unit. The
IEPMU02 Power Mounting Unit is a front mounted unit.
Module Mounting Units
The IEMMU01 Module Mounting Unit provides the housing,
power connections and signals for power supply and process
control modules. The module mounting unit is an alternative
to the power mounting unit.
The IEMMU02 unit has the same functionality as the
IEMMU01 unit, but it is a front mounted unit. Its primary use
is in smaller system cabinets like the MINI-90™ system.
USER QUALIFICATIONS
This manual is not a tutorial. Therefore, the user should have
training as an electrical technician. That is, the user should
know the basics of, and precautions for, working with AC/DC
voltages, and how to use various measuring instruments such
as digital voltmeters.
INSTRUCTION CONTENT
This manual provides introductory, installation, operation,
troubleshooting and maintenance information. Read and
™ MINI-90 is a trademark of Elsag Bailey Process Automation.
