INTRODUCTION
I-E96-506B1 7 - 1
SECTION 7 - REPAIR/REPLACEMENT PROCEDURES
INTRODUCTION
Although the modular power system is designed to give long,
troublefree service, some components may need to be replaced
periodically. This section explains the replacement procedures
and lists spare part numbers.
SPARE PARTS
Table 7-1 lists a description and Bailey part number of spare
parts that can be stocked. It is impractical to specify a recom-
mended quantity of spare parts because Bailey Controls Com-
pany custom designs every system. Contact Bailey Controls
Company for help determining the quantity of spare parts to
keep on hand for your particular system.
® Bussman is a registered trademark of McGraw Edison Company.
Table 7-1. Spare Part Numbers and Description
Description Part No./Nomenclature Remarks
AC field power module IEPAF02 Can replace an IEPAF01 module
AC power cables 6637814_2 Connects PEP to PMU or to input power bus
bar
6637818_2 Connects input power bus bar to MMU
AC system power module IEPAS02 Can replace an IEPAS01 module
AC transfer module 6637827_1 Used in IEPEP03
Bus monitor module 6637830_1 Used in IEPEP03
Cabinet filter 199914_20 IECAB01and IECAB03
DC power cable 1948509_5 Connects MMU to system power bus bar
Fuse, 1 A Bussman
®
AGC1
or equivalent
194776A11001
Fuse in IEFAN02 assembly
Fuse, 2 A Bussman AGC2
or equivalent
194776A12001
Fuse in IEFAN01 assembly
Fuse, 3 A Bussman GMA-3 fast act-
ing or equivalent
1948182_23001
Fuse in IEPAS02 and IEPAF02 modules
IEFAN01 assembly (120 VAC) 1947419_1 —
IEFAN02 assembly (240 VAC) 1947419_2 —
Insulated quick connect
receptacle
1948529_1 —
PFI cable 6638084_1 Connects IEPEP01/02 to system power bus
bar
