INTRODUCTION
I-E96-506B1 3 - 1
SECTION 3 - INSTALLATION
INTRODUCTION
Completely install and prepare the hardware before applying
power (i.e., attach wiring to terminal blocks, etc.). This section
explains hardware preparation in detail.
NOTE:
Normally, the cabinet is fully wired and ready to go upon
receipt. The following information is provided in the event that you
need to repair, replace, rewire or add to the modular power system.
UNPACKING AND INSPECTION
The power modules are in separate packages from the rest of
the power system. Follow the guidelines in Special Handling
when handling these modules.
Special Handling
Observe these steps when handling electronic circuitry:
NOTE:
Always use Bailey's field static kit (part number 1948385A1 -
consisting of two wrist straps, ground cord assembly, alligator clip
and static dissipative work surface) when working with the modules.
The kit grounds a technician and the static dissipative work surface
to the same ground point to prevent damage to the modules by elec-
trostatic discharge.
1. Use Static Shielding Bag. Keep the modules in the static
shielding bag until you are ready to install them in the system.
Save the bag for future use.
2. Ground Bag Before Opening. Before opening a bag con-
taining an assembly with semiconductors, touch it to the
equipment housing or a ground to equalize charges.
3. Avoid Touching Circuitry. Handle assemblies by the
edges; avoid touching the circuitry.
4. Avoid Partial Connection of Semiconductor. Verify that
all devices connected to the modules are properly grounded
before using them.
5. Ground Test Equipment.
6. Use Antistatic Field Service Vacuum. Remove dust from
the module if necessary.
7. Use a Grounded Wrist Strap. Connect the wrist strap to
the appropriate grounding plug on the power entry panel. The
