REPAIR/REPLACEMENT PROCEDURES
POWER ENTRY PANEL REPLACEMENT
7 - 6 I-E96-506B1
®
POWER ENTRY PANEL REPLACEMENT
1. Turn off power to the cabinet at the AC power source.
2. Open the rear door of the cabinet to gain access to the rear
of the power entry panel.
3. Remove all wiring from the power entry panel. Label the
wires as you remove them.
4. From the rear of the cabinet, use a 16-inch bladed screw-
driver to remove the 4 mounting screws.
5. Pull the power entry panel out of the cabinet.
6. From the rear of the cabinet, insert the replacement power
entry panel in the same mounting space.
7. Secure the power entry panel to the cabinet with the 4
mounting screws.
8. With power entry panel circuit breakers off, connect the
wiring that was removed in Step 3. Appendix C contains power
entry panel wiring diagrams.
9. If it is an IEPEP01 or IEPEP02 panel, check the 120/
240 VAC switch to verify that it is set for the correct line volt-
age.
10. If it is an IEPEP03 panel, set the jumpers and dipswitches
on the bus monitor module for the desired operation. Verify
that the switch on the AC transfer module is set for the correct
line voltage.
11. Turn on the power to the power entry panel at the AC
source.
12. Turn on the power to the cabinet at the power entry panel
circuit breakers and check for proper operation.
WARNING
Verify the main power and power entry panel circuit breakers
are turned off before starting installation, retrofit, upgrade, or
wiring procedures. Failure to do so could result in severe or
fatal shock. Do not turn the power on until the installation, ret-
rofit, upgrade, or wiring procedures are complete.
AVERTISSEMENT
Assurez-vous que le disjoncteur d'alimentation principal et le
disjoncteur de panneau d'entrée des alimentations sont éteints
avant de procéder à l'installation, à la mise à jour, à l'extension
ou au câblage, dans le but d'éviter les chocs sérieux et même
mortels. Ne rétablissez pas l'alimentation tant que ces procé-
dures ne sont pas terminées.
