INTRODUCTION
REFERENCE DOCUMENTS
1 - 4 I-E96-506B1
®
REFERENCE DOCUMENTS
Table 1-1 lists reference documents.
NOMENCLATURE
Table 1-2 lists nomenclatures associated with the IEPAS02
and IEPAF02 Power Supply Modules. Refer to Table 7-1 for
part numbers of related items such as cables and fuses.
GLOSSARY OF TERMS AND ABBREVIATIONS
Table 1-3 is a glossary of terms and abbreviations used in this
manual.
Table 1-1. Reference Documents
Document
Number
Title
I-E96-500 Site Planning and Preparation
Table 1-2. Nomenclature
Nomenclature Description
IEFAN01 Fan assembly - 120 VAC
IEFAN02 Fan assembly - 240 VAC
IEFAS01 INFI 90 fastener kit
IEMMU01 Module mounting unit (rear mount)
IEMMU02 Module mounting unit (front mount)
IEPAF02 AC field power module
IEPAS02 AC system power module
IEPEP01 Power entry panel with single AC feed and no circuit
breaker
IEPEP02 Power entry panel with single AC feed and circuit breaker
IEPEP03 Power entry panel with redundant AC feed and circuit
breakers
IEPMU01 Power mounting unit (rear mount)
IEPMU02 Power mounting unit (front mount)
Table 1-3. Glossary of Terms and Abbreviations
Term Definition
ATM AC transfer module.
BMM Bus monitor module.
Controlway High speed, redundant, peer-to-peer communication link. Used to transfer information
between intelligent modules within a process control unit.
