INTRODUCTION
I-E96-506B1 A - 1
APPENDIX A - QUICK REFERENCE GUIDE
INTRODUCTION
Use Table A-1 as a quick reference to check jumper and switch
settings for the IEPAS02 and IEPAF02 Power Modules, bus
monitor module and AC transfer module.
Table A-1. Switch and Jumper Setting Reference Guide
Device
Switch
Position
Jumper
Position
Function
AC transfer
module
S1 - 120
S1 - 240
120 VAC operation
240 VAC operation
Bus monitor
module
S1 = 0011 Factory default setting, 5,
±
15, 24 VDC monitoring enabled.
External monitoring disabled.
J1
1-2
2-4
2-3
Auxiliary bus monitor, channel 1:
Selects 24 VDC external power
Selects 48 VDC external power
Selects 125 VDC external power
J2
1-2
2-4
2-3
Auxiliary bus monitor, channel 2:
Selects 24 VDC external power
Selects 48 VDC external power
Selects 125 VDC external power
J3
1-2
2-3
AC input voltage, line 2:
Selects 120 VAC input
Selects 240 VAC input
J4
1-2
2-3
3-4
Auxiliary status input 1:
Normally open status input
Normally closed status input
Not used
J5
1-2
2-3
Auxiliary status input 2:
Normally open status input
Normally closed status input
J6
1-2 Must be set as shown
J7
1-2
2-3
AC input voltage, line 1:
Selects 120 VAC input
Selects 240 VAC input
J8
2-3 Must be set as shown
