Bailey Infi 90 - Bus Monitor Module Switch Settings; Bus Monitor Module Jumper Settings

INSTALLATION
IEPEP03 POWER ENTRY PANEL WIRING
3 - 8 I-E96-506B1
®
Table 3-1. Bus Monitor Module Switch Settings
Switch S1 Position
Function
1
1234
0 Enable 5,
±
15 VDC monitoring
1 Disable 5,
±
15 VDC monitoring
0 Enable 24 VDC monitoring
1 Disable 24 VDC monitoring
0 Enable auxiliary bus monitoring CH1
1 Disable auxiliary bus monitoring CH1
0 Enable auxiliary bus monitoring CH2
1 Disable auxiliary bus monitoring CH2
NOTES:
0 = CLOSED or ON, 1 = OPEN or OFF
1. Do not enable all inputs simultaneously. Doing so will cause a bad status signal. Unused monitor
inputs must be disabled. Figure 3-4 shows the factory settings of switch S1.
Table 3-2. Bus Monitor Module Jumper Settings
Jumper
Number
Jumper
Position
Function
1
J1
1-2
2-4
2-3
Auxiliary bus monitor, channel 1:
Selects 24 VDC external power
Selects 48 VDC external power
Selects 125 VDC external power
J2
1-2
2-4
2-3
Auxiliary bus monitor, channel 2:
Selects 24 VDC external power
Selects 48 VDC external power
Selects 125 VDC external power
J3
1-2
2-3
AC input voltage, line 2:
Selects 120 VAC input
Selects 240 VAC input
J4
1-2
2-3
3-4
Auxiliary status input 1:
Normally open status input
Normally closed status input
Not used
J5
1-2
2-3
Auxiliary status input 2:
Normally open status input
Normally closed status input
J6 1-2 Must be set as shown
J7
1-2
2-3
AC input voltage, line 1:
Selects 120 VAC input
Selects 240 VAC input
J8 2-3 Must be set as shown
NOTE:
1. Placing a shorting strap over the jumper pins selects the function.
