INSTALLATION
IEPEP03 POWER ENTRY PANEL WIRING
I-E96-506B1 3 - 9
Fan Assembly
The IEFAN01 or IEFAN02 fan assembly mounts directly
beneath the power entry panel and above the power mounting
unit or the first module mounting unit (see Figure C-2). Attach
the fan power cable to the J1 connector on the power entry
panel.
Power Modules
Power modules mount directly in the module mounting unit or
power mounting unit. Use any slot except the right-most slot
(slot 12) when mounting a power module in a module mount-
ing unit.
Mount the power modules in any slot when using a power
mounting unit. Figure 3-5 shows the recommended mounting
pattern and spacing when mounting power modules in module
mounting units. This installation scheme provides the best
heat dissipation and power distribution. For optimum heat dis-
sipation and power distribution, do not exceed more than two
IEPAS02 modules in any module mounting unit. Install at least
one IEPAS02 module in the module mounting unit with the
largest load (e.g., a module mounting unit containing several
multi-function processor modules).
NOTE:
Power mounting units can hold a maximum of 12 power
modules mounted side by side. However the total five VDC current
load on the power mounting unit cannot exceed 100 amps. The total
24 VDC current load on the power mounting unit cannot exceed
60 amps.
Before handling the power modules:
1. Verify that all devices connected to the module are properly
grounded before using them.
2. Avoid touching the circuitry when handling the module.
3. Always use grounding straps (field static kits) when work-
ing with the modules.
WARNING
Do not remove the plastic covers on the module mounting unit
backplane. These covers protect against accidental contact
with AC voltage. Severe or fatal shock could result.
AVERTISSEMENT
Ne retirez pas les couvercles de plastique situés sur le pan-
neau arrière du châssis de montage des modules. Ces couver-
cles constituent une protection contre les contacts accidentels
avec la tension c.a., qui risquent de provoquer des chocs
sérieux et même mortels.
