MODULE POWER REQUIREMENTS
SIZING THE MODULAR POWER SYSTEM
I-E96-506B1 B - 7
Substitute these values into the equations and solve for Q.
QS
= Largest of Q1, Q2, Q3, Q4 and Q5 = 2.038
Number of power modules required for system.
QS
= 2.038
Round the value of QS to the next highest integer.
QS
= 3 IEPAS02 modules
With N+1 redundancy where N = QS.
QS
(N+1)
= 3 + 1 = 4 IEPAS02 modules
For Systems Using Both IEPAS02 and IEPAF02 Modules
Let:
A
Total 5 VDC current requirements for system cabinet.
B
Total 24 VDC current requirements for associated I/O.
C
Total +15 VDC current requirements for system cabi-
net.
D
Total -15 VDC current requirements for system cabinet.
Q1
Number of IEPAS02 power modules needed to meet 5 V
current requirements.
Q2
Number of IEPAS02 power modules needed to meet 24
V current requirements.
Q3
Number of IEPAS02 power modules needed to meet +15
V current requirements.
Q1
26.5
13
-----------
2.038
==
Q2
3.1
4
--------
0.775
==
Q3
0.9
0.8
--------
1.125
==
Q4
0.4
0.8
--------
0.5
==
Q5
26.5 5.225
×〈〉
3.1 25.8
×〈〉
0.9 15.3
×〈〉
0.4 15.3
+〈〉+++
130
---------------------------------------------------------------------------------------------------------------------------------------------------------=
138.46 79.98 13.77 6.12
+++
〈〉
130
------------------------------------------------------------------------------------
1.833
==
