RETROFITTING THE MODULAR POWER SYSTEM
NETWORK 90 POWER SYSTEM REMOVAL
I-E96-506B1 D - 5
10. Install the power entry panel directly above the fan
assembly.
11. Install row 0 spacer.
Wiring the INFI 90 Power System
NOTE:
Before wiring the system, verify the AC transfer module and
bus monitor module switch and jumper settings are correct. Refer to
Section 3 for switch and jumper setting information; see Figures D-1
and D-2 for wiring diagrams of the INFI 90 modular power system in
a Network 90 cabinet.
1. Attach one end of the 6 AWG wire assembly to PMU I/O
COM. Attach the other end to the isolated system common
bus.
2. Connect the +24 VDC, originally from TB2 and TB3 of the
I/O power panel, to the +24 VDC bus bar on the PMU back-
plane by stacking all wires onto a 6 AWG lug (or connect each
wire [6 total] separately).
3. Slide heat shrink tubing over the PMU connection (see
Figure 3-9).
4. Wire the auxiliary status input to TB3 (IEPEP03 panel
only). Refer to the IEPEP03 installation procedure in Section 3
for more details.
5. Attach the AC cable (part number 6637814_2) from TB2 on
the IEPEP03 panel or TB3 on the IEPEP01 and IEPEP02 panels
to the AC terminal block on the PMU backplane.
6. Attach the J2 molex connector (part number 6637813_1) to
the J2 socket on the IEPEP03 panel. Attach part number
6638084_1 to PFI on the IEPEP01 or IEPEP02 panel.
7. Attach the other ends of the J2 connector (or PFI) as shown
in the wiring diagrams (see Figures D-1 and D-2).
8. Connect the status signal wires removed in Step 7 of Power
Entry Panel Removal in this section to TB3-4. Wire COM on
TB3-2 to the isolated system common bus bar (IEPEP03 panel
only).
9. Attach any auxiliary bus monitor (24, 48, 125 VDC) input
wires to TB4 (IEPEP03 panel only).
10. Attach fan cable to J4 on IEPEP01 and IEPEP02 panels, or
J1 on IEPEP03 panel.
11. Connect the cabinet ground wire to the ground stud on the
PEP panel.
