INSTALLATION
IEPEP03 POWER ENTRY PANEL WIRING
3 - 2 I-E96-506B1
®
grounding plug on the power entry panel must be effectively
connected to the earth grounding electrode system through the
AC safety ground.
8. Do Not Use Lead Pencils to Set Dipswitches. To avoid
contamination of switch contacts that can result in unneces-
sary circuit board malfunction, do not use a lead pencil to set a
dipswitch.
General Handling
1. Examine the hardware immediately to verify that it has not
been damaged in transit.
2. Notify the nearest Bailey Controls Company sales office of
any such damage.
3. File a claim for any damage with the transportation com-
pany that handled the shipment.
4. Use the original packing material and container to store the
hardware.
5. Store the hardware in an environment of good air quality,
free from temperature and moisture extremes.
IEPEP03 POWER ENTRY PANEL WIRING
The appendices at the back of this manual show complete wir-
ing diagrams of the modular power system. Figures C-1 and
C-2 show the IEPEP03 system cabinet wiring diagram.
NOTE:
Plug your wrist strap ground cord into the receptacle labeled
WRIST STRAP GND when working with the system.
1. Place circuit breakers CB1 and CB2 (see Figure 3-1) on the
front of the panel to the off position before connecting AC
power input wiring.
WARNING
Verify the main power and power entry panel circuit breakers
are turned off before starting installation, retrofit, upgrade, or
wiring procedures. Failure to do so could result in severe or
fatal shock. Do not turn the power on until the installation, ret-
rofit, upgrade, or wiring procedures are complete.
AVERTISSEMENT
Assurez-vous que le disjoncteur d'alimentation principal et le
disjoncteur de panneau d'entrée des alimentations sont éteints
avant de procéder à l'installation, à la mise à jour, à l'extension
ou au câblage, dans le but d'éviter les chocs sérieux et même
mortels. Ne rétablissez pas l'alimentation tant que ces procé-
dures ne sont pas terminées.
