Basler BE1-11g User Manual

194 9424200994 Rev N
Table 75. Targets as Displayed
Target
Description
21-#-AB
Distance, AB
21-#-BC
Distance, BC
21-#-CA
Distance, CA
24
Overexcitation
27P-#-A/B/C
Phase Undervoltage, A, B, or C
27X-#-3V0
Auxiliary Undervoltage, 3V0-3ph VT
27X-#-V1
Auxiliary Undervoltage, Positive-Sequence
27X-#-V2
Auxiliary Undervoltage, Negative-Sequence
27X-#-AUX
Auxiliary Undervoltage, Fundamental VX
27X-#-3RD
Auxiliary Undervoltage, 3
rd
Harmonic VX
32-#-A/B/C/T-Over
Power, Phase A, B, C, or Total, Overpower
32-#-A/B/C/T-Under
Power, Phase A, B, C, or Total, Underpower
40Q
Loss of Excitation, Reverse var Based
40Z Z1/Z2
Loss of Excitation, Impedance Based, Zone 1 or 2
40Z Z1/Z2 VC
Loss of Excitation, Impedance Based, Zone 1 or 2, Voltage Control
49RTD-# RTD-#-#
Over/Undertemperature
50-#-A/B/C
Instantaneous Overcurrent, Phase A, B, or C
50-#-Residual
Instantaneous Overcurrent, Residual
50-#-IND GND
Instantaneous Overcurrent, Independent Ground
50-#-Pos SEQ
Instantaneous Overcurrent, Positive-Sequence
50-#-Neg SEQ
Instantaneous Overcurrent, Negative-Sequence
50-#-Unbalance
Instantaneous Overcurrent, Unbalance
50-#-67-A/B/C
Directional Instantaneous Overcurrent, Phase A, B, or C
50-#-67-Residual
Directional Instantaneous Overcurrent, Residual
50-#-67-IND GND
Directional Instantaneous Overcurrent, Independent Ground
50-#-67-Neg SEQ
Directional Instantaneous Overcurrent, Negative-Sequence
50BF
Breaker Failure
51-#-A/B/C
Inverse Overcurrent, Phase A, B, or C
51-#-Residual
Inverse Overcurrent, Residual
51-#-IND GND
Inverse Overcurrent, Independent Ground
51-#-Pos SEQ
Inverse Overcurrent, Positive-Sequence
51-#-Neg SEQ
Inverse Overcurrent, Negative-Sequence
51-#-Unbalance
Inverse Overcurrent, Unbalance
51-#-67-A/B/C
Directional Inverse Overcurrent, Phase A, B, or C
51-#-67-Residual
Directional Inverse Overcurrent, Residual
51-#-67-IND GND
Directional Inverse Overcurrent, Independent Ground
51-#-67-Neg SEQ
Directional Inverse Overcurrent, Negative-Sequence
59-#-A/B/C
Phase Overvoltage, A, B, or C
Fault Reporting BE1-11g
