Table 131. Definite Time Verification Test Settings
Disables Inverse Time Pickup
Sets Definite Timer 1 Pickup at 118% of nominal (2.36 V/Hz)
Definite Timer 1 Time Delay
Sets Definite Timer 1 Time Delay at 500 ms
Step 2: Connect and apply 120 Vac, three-phase, 60-hertz voltage source to Terminals C13 (A-phase),
C14 (B-phase), C15 (C-phase), and C16 (neutral).
Step 3: Step the A-phase voltage to 142.2 V (118.5% or 2.37 V/Hz). Measure the time between the
increase in voltage and the closure of OUT1. Record the result.
Step 4: Repeat steps 1 through 3 for Time Delays of 1 second and 5 seconds. Record the results.
Step 5: (Optional.) Repeat steps 1 through 4 for the B-phase and C-phase voltage inputs.
Step 6: (Optional.) Repeat steps 1 through 5 for settings group 1, 2, and 3.
Step 7: (Optional.) Set Definite Timer 1 Pickup to 0 and Definite Timer 2 Pickup to 2.36 V/Hz and repeat
steps 1 through 6 for Definite Timer 2.
Functional Test Report
Alarm Verification
Alarm Setting Range = 0.5 to 6 V/Hz
Alarm Accuracy = ±2% or ±0.05 V/Hz, whichever is greater
Alarm/Reset Ratio = 98% ±1%
Step
Low
High
Low*
High*
Pass/Fail
* Reset range is calculated from the alarm setting and may need adjusted based on actual alarm.
Inverse Time Pickup Verification
Pickup Setting Range = 0.5 to 6 V/Hz
Pickup Accuracy = ±2% or ±0.05 V/Hz, whichever is greater
Dropout/Pickup Ratio = 98% ±1%
Step
Low
High
Low*
High*
Pass/Fail
* Dropout range is calculated from the pickup setting and may need adjusted based on actual pickup.
Definite Time Pickup Verification
Pickup Setting Range = 0.5 to 6 V/Hz
Pickup Accuracy = ±2% or ±0.05 V/Hz, whichever is greater
Dropout/Pickup Ratio = 98% ±1%
BE1-11g Overexcitation (24) Test
