354 9424200994 Rev N
Transformer
Connection
CT Input
Connection
BE1-11
g
Settings
Compensation Applied
TX CT Phase Rotation
ZAC WYE ZAC WYE WYE R2
Table 117. CT Input Circuit Settings 2 for Delta/Wye Circuit Applications
Transformer
Connection
CT Input
Connection
BE1-11g Settings
Compensation Applied
TX
CT
Phase
Rotation
WYE
WYE
WYE
WYE DAB NONE
WYE
DAB WYE DAB WYE NONE
WYE DAC WYE DAC WYE R2
DAB WYE DAB WYE WYE NONE
DAC WYE DAC WYE WYE R2
ZAB WYE ZAB WYE WYE NONE
ZAC WYE ZAC WYE WYE R2
