9424200994 Rev N 355
Table 118. CT Input Circuit Settings 3 for Delta/Wye Circuit Applications
Transformer
Connection
CT Input
Connection
BE1-11g Settings
Compensation Applied
TX CT Phase Rotation
WYE
WYE
WYE
WYE DDAB NONE
WYE
DAB WYE DAB DAB NONE
WYE DAC WYE DAC DAB R2
DAB WYE DAB WYE DAB NONE
DAB DAB DAB DAB WYE NONE
DAB DAC DAB DAC WYE R2
DAC WYE DAC WYE DAB R2
DAC DAB DAC DAB WYE R2
