Transformer
Connection
CT Input
Connection
BE1-11
g
Settings
Compensation Applied
TX CT Phase Rotation
DAC DAC DAC DAC WYE R1
ZAB WYE ZAB WYE DAB NONE
ZAB DAB ZAB DAB WYE NONE
ZAB DAC ZAB DAC WYE R2
ZAC WYE ZAC WYE DAB R2
ZAC DAB ZAC DAB WYE R2
ZAC DAC ZAC DAC WYE R1
Configuration BE1-11g
