402 9424200994 Rev N
Table 150. Timing Test Settings (Vx Fundamental Mode)
Pickup Setting
Time Delay
115 V
2,000 ms
115 V
5,000 ms
115 V
10,000 ms
Step 2: Prepare to monitor the 27X-1 timings. Timing accuracy is verified by measuring the elapsed
time between a sensing voltage change and OUT1 closing.
Step 3: Connect and apply a 120 Vac, single-phase voltage source to terminals C17 (polarity) and C18
(non-polarity).
Step 4: Step the voltage down to 110 volts. Measure the time delay and record the result.
Step 5: Repeat step 4 for the 5,000 ms and 10,000 ms time delay settings of Table 150. Record the
results.
Step 6: (Optional.) Repeat steps 1 through 5 for settings group 1, 2, and 3.
Step 7: (Optional.) Repeat steps 1 through 6 for 27X-2, 27X-3, and 27X-4.
Pickup Verification (Vx Third Harmonic Mode)
Step 1: Use BESTCOMSPlus to send the operational settings in Table 151 to the BE1-11g. Reset all
targets.
Table 151. Operational Settings (Vx Third Harmonic Mode)
Setting
Value
BESTCOMSPlus Screen
Description
Aux VT Ratio
1
System Parameters, Sensing
Transformers
Sets auxiliary VT ratio to 1
Aux VT
Connection
AN
System Parameters, Sensing
Transformers
Sets auxiliary VT connection to
AN
Element Mode
Vx Third
Harmonic
Protection, Voltage,
Undervoltage (27X-1)
Enables 27X-1 function for Vx
Third Harmonic mode
Inhibit Level
10 V
Protection, Voltage,
Undervoltage (27X-1)
Sets inhibit level to 10 V
Timing Mode
Definite
Protection, Voltage,
Undervoltage (27X-1)
Selects definite timings
27X-1 3RD
Enabled
Target Configuration, Targets
Enables Vx Third Harmonic
target for 27X-1
Step 2: Use BESTCOMSPlus to configure the BESTlogicPlus programmable logic shown in Figure 283.
• Blocking is disabled.
• OUT1 closes for 27X-1 Trip.
• OUT2 closes for 27X-1 Pickup.
• Fault recording is enabled.
Auxiliary Undervoltage (27X) Test BE1-11g
