9424200994 Rev N 657

Manual

Revision and Date

Change

N, Sep-14

• Added Conformal Coating to Option 2 in Figures 1 and 264

• Added power supply burden for J type case

• Corrected Figures 337 (A1 Curve), 348 (B1 Curve), and 353 (C1

Curve) in the Time Curve Characteristics chapter

• Text edits throughout manual

BE1-11g Revision History
