Technical Data
Instruction handbook b maXX BM5500, BM5600, BM5700
Document No.: 5.13008.10
109
of 314
3
3.5.5 Electrical data BM556X power module
BM5562-
XXX8
BM5563-
XXX8
Rated input power
1)
150 kW 180 kW
Rated input current
1)
(I
eff
) 278 A 335 A
Max. input current (I
eff
) 392 A 436 A
Rated DC link voltage
1)
(U
DC
) 540 V
DC
DC link capacitance (internal) 5170 µF 6110 µF
DC link discharging time
(internal DC link capacitance)
120 s 170 s
Output voltage
1)2)
(U
AC
) 3 x 0 V to 3 x 370 V
Output frequency at 4 kHz
10)
0 Hz to 450 Hz
Rated output current
1)4)5)6)11)
(I
AC
) at 4 kHz
3)
250 A 300 A
Rated output current
1)4)5)6)11)
(I
AC
) at 8 kHz
3)
200 A 240 A
Output peak current
1)4)5)7)11) (
I
AC
) at 4 kHz
3)
325 A 390 A
Output peak current
1)4)5)7)11)
(I
AC
) at 8 kHz
3)
260 A 312 A
Max. peak current period
7)
60 s
Power loss referring to the power input 3230 W 3920 W
Power loss referring to th
e control voltage 93 W
Power loss of the device fan
referring to 230 V
AC
8)
174 W
Current of the integrated brake control Max. 8.0 A
9)
Cooling air requirement power heatsinks 450 m³/h
Cooling air requirement device internal space 200 m³/h
.
1)
All rated values refer to a DC link voltage of 540 V
DC
and a control voltage of 24 V.
2)
The output voltage is a pulsed DC voltage. The operating range refers to the RMS of the fundamental wave.
U
AC
3 0 V to 3
U
DC
2
----------- 10 V–
=
without overmodulation of the PWM.
3)
Switching frequency of the inverter (adjustable).
4)
RMS at an environmental temperature of 40 °C.
