Technical Data
Instruction handbook b maXX BM5500, BM5600, BM5700
Document No.: 5.13008.10
115
of 314
3
Figure 54: Braking cycle
P
D
Average continuous brake power of one cycle
P
Dmax
Maximum continuous brake power, refer to ZTechnical data brake resis-
tors– on page 113
n Number of brake operations within one cycle
P
S_1
to P
S_n
Brake peak power, numbered in chronological order
t
on_1
bis t
on_n
Brake time periods
t
off_1
bis t
off_n
Off time periods, between the brake time periods
T
cycle
Total cycle
C
1
, C
2
, C
3
Constants, refer to ZTechnical data brake resistors– on page 113
brake
on_1
off_1
on_2
off_2
on_n
off_n
on_1
cycle
