Baumuller b maXX 5500 - Page 153

Mounting
Instruction handbook b maXX BM5500, BM5600, BM5700
Document No.: 5.13008.10
153
of 314
6
Figure 73: Mounting instruction BM555X-S/Z, BM556X-S/Z
Device BM555X-S/Z
BM565X-Z
BM556X-S/Z
BM566X-Z
A - Screws 4x M8 4x M8
B - Washers 4x (8.4x21) 4x (8.4x21)
C - Mounting space c=7 mm c=7 mm
