Mounting
Instruction handbook b maXX BM4400, BM4600, BM4700
Document No.: 5.12008.07
157
of 358
6
Figure 70: Mounting instruction BM445X-S/Z, BM465X-S/Z, BM446X-S/Z, BM466X-S/Z
Device BM445X-S/Z
BM465X-Z
BM446X-S/Z
BM466X-Z
A - Screws 4x M8 4x M8
B - Washers 4x (8.4x21) 4x (8.4x21)
C - Mounting space c=7 mm c=7 mm
