Controller terminals
Instruction handbook b maXX BM4400, BM4600, BM4700
Document No.: 5.12008.07 Baumüller Nürnberg GmbH
200
of 358
7.11
X3 Ready for use ON (SELV/PELV)
Quick stop (SELV/PELV)
Pulse enable (SELV/PELV)
Notes on the usage of an OSSD test pulse see ZC.4 Re
quirements on an OSSD test
pulse– on page 349.
X5/X6
X5 IN
1: TX+
2: TX-
3: R
X+
4: re
served
5: re
served
6: R
X-
7: re
served
8: re
served
X6 OUT
1: TX+
2: TX-
3: R
X+
4: re
served
5: re
served
6: R
X-
7: re
served
8: re
served
depends on ES controller type
BM4XXX - XXX - XXXXX[Ryy] - 1X (
with EtherCAT
®
interface)
Max. cross-section
of connection
Connection
technology
Load capacity /
voltage level
1.5 mm
2
Plug-in contact Ready for use ON; X3-1, X3-2
and X3-6:
max. 0.2 A
Quick stop; X3-4
Pulse enable; X3-5:
0 (low) 0 V to 5 V
1 (high) 12 V to 28 V
NOTE!
Setting the IP address, see ZEtherCAT
®
– from page 136.
