Technical Data
Instruction handbook b maXX BM4400, BM4600, BM4700
Document No.: 5.12008.07
45
of 358
3
Figure 19: Dimensions BM446X-A/F and BM466X-A/F
*: Observe minimum clearance, Observe ZCooling– from page 61.
**: Dimensions specified with design cover. The ES controller is not
equipped with a design cover.
***: Width including screw heads
NOTE!
The device BM4X6X-AX-0XXX was extended by about 80 mm downwards by an ad-
ditional protective plate against contact.
