07-19-B3-430 Auto Syringe AS50 Infusion Pump Operator’s Manual Page 17
General Information
Field #3 displays dose duration (HH:MM), or
patient body weight (kg).
Field #4 displays dose interval (
HH:MM), drug
concentration (mg/mL, or U/mL), or bolus size
(Units or mL).
Field #5 displays time remaining until the next
dose is due (hh:mm), dose size (mcg/min,
mcg/hr, mg/min, mg/hr, mcg/kg/min, mcg/kg/hr,
mg/kg/min, mg/kg/hr, mU/min, mU/hr, U/min, or
U/hr) or bolus size (mg, mcg/kg, mg/kg, or
Units).
Field #6 displays total delivered (mL, mcg, mg,
or grams), volume limit (mL), bolus size (mL),
or final volume (mL).
Field #7 displays total delivered (mL), or drug
volume to be mixed with infusion base solution
(mL).
Field #8 displays text prompts and messages.
O
VER
B
OD
Y
WT
hr
:min
k
g
EVER
Y
CO
N
C
.
U
nit
s
hr
:min
L
m
g
m
NEXT
D
OSE
IN
hr
:min
mc
g
k
g
U
m
g
hr
TOT
AL FINAL
T
T
m
g
ram
s
mLmc
g
V
O
L LIMITV
OL
TOT
AL
T
T
L
m
DR
UG
V
O
L
