45
6-847718-00 Rev. B00
The wiring schematics listed below are
provided.
Call BeaconMedæs at 1-888-4MEDGAS
(1-888-463-3427) for technical support.
1. Power Supply (Page 46)
2. Sensor Module to Digital Display
Module (Page 47)
3. Multiplexer/Breakout Boards (Page 48)
4. Relay Board (Page 49)
5. Multi-Signal Module Inputs (Page 50)
6. Digital Display Module Master/Slave
(Page 51)
7. Multi-Signal Module Relay Outputs
(Page 52)
8. General Fault/Auxiliary Relays
(Page 53)
9. Digital Display Module High/Low Relays
(Page 53)
10 Remote Pressure/Vacuum Switches
(Page 54)
11 Johnson Controls Metasys® N2
Connection (Page 55)
Wiring Schematics
