Technical data | MS 63 | 37 en
9. Technical data
9.1 MS 63
Function Specifications
Maximum noise level 75 dB
Bead breaking cylinder force 11 kN
Compressed air supply 8 – 10 bar
Power supply tension depending on the cho
-
sen tension (see iden-
tification plate)
9.2 Temperatures and operating range
Function Specification
Operating temperature -5° C \ +40° C
Storage temperature -20° C \ + 60° C
Temperature gradient 20° C
Relative humidity in operation 10% \ 90% (40° C)
Relative humidity gradient 10%
Installation height -200 mt. \ 3.000 mt.
Transportation height -200 mt. \ 12.000 mt.
9.3 Dimensions and weights
Function Specifications
MS 63 (H x W x D) 1940 x 1200 x 170 mm
Net weight 204 kg
Gross weight 236 kg
9.4 Reach
9.4.1 Car wheels
Function min / max
Tire width 3"– 10"
Maximum tire diameter 1000 mm
Rim diameter (internal locking) 10"– 20"
Rim diameter (external locking) 12"– 23"
9.4.2 Motorcycle wheels
Function min / max
Tire width 3"– 7"
Maximum tire diameter 1000 mm
Rim diameter 14"– 25"
i To operate on motorbike wheels it is necessary to
install the motorbike wheel connection device, avai-
lable upon request (see chap. 3.4).
8. Glossary
Rim, structure and designations
652001-26_Rf
1
1
3
4
3
2
D
Fig. 3: Rim
1 Rim flange
2 Bead seat
3 Hump
4 Drop center
D Rim diameter
RFT
Run Flat Tire
TCE
Tire Change Equipment
UHP
Ultra High Performance tire
wdk
Association of the German rubber industry
