Benelli TNT 25 - Sprocket, Shaft Sleeve, Shaft Sleeve Bearing

Sprocket, Shaft Sleeve, Shaft Sleeve Bearing
Disassembling Rear Sprocket
•Disassembling rear wheel (see “Wheel / Tire”—“Disassembling
Rear Wheel”).
Note
Do not place the wheel on the ground horizontally and make
the brake disc towards, otherwise, brake disc may be damaged
or deformed. Please place wood blocks below wheel, to prevent
brake disc from contacting the ground.
•Disassemble:
Rear sprocket nut [A],
Rear sprocket [B]
Installing Rear Sprocket
•When installing the sprocket, the side with the sign of number of
teeth [A] should be towards the outside.
•Lock rear sprocket nut.
Locking Torque of Rear Sprocket Nut: 45N·m
•Install rear wheel (see “Wheel / Tire”—“Installing Rear Wheel”).
6-29
