Benelli TNT 25 - Clutch Cable Routing

To Next Page

To Previous Page

Clutch Cable Routing:

Run the clutch cable

through the gap between

the meter and upper

bridge

Run the clutch cable

through the frame as

shown. Do not interfere

with the throttle cable.

8-9
