Replacement Part
Replacing Air Filter Element
Remark
○If the motorcycle is used in a dusty environment, the replacement
interval of air filter element shall be shorter than the recommended
replacement interval.
○After riding in rainy days or on muddy roads, replace the air filter
element immediately.
Warning
If the dirt or dust enters into the throttle valve body assembly,
the throttle may be blocked and safety accidents may be caused.
Note
If the dirt enters into the engine, the excessive wear of engine
will be caused, or even the engine may be damaged.
●Remove the rear seat [2]
●Remove the fixing screw [A] and disassemble the front seat [1]
●Remove the tool box mounting bolt [3] and take the tool box.
2-51
