Replacing Oil
●After the engine becomes hot, place the motorcycle vertically and
make it be perpendicular to the ground.
●Remove the oil drain bolt [A] to discharge the oil.
○Place an appropriate container under the oil drain bolt [A] to
collect the oil.
●Drain: oil in the crankcase.
●Tighten the oil drain bolt.
Tightening torque of oil drain bolt: 22 N·m
●Pour the oil of the specified type according to the specified quantity.
Note
Make sure that the oil level is between the oil lens [A]
Recommended oil
Model: API SE, SF or SG
API SH, SJ or SL, JASO MA, MA1 or MA2
Viscosity: SAE 10W-50
Capacity: 1.2 L (when replaced);
1.5L (Engine is disassembled completely)
Remark
○Do not add any chemical additives to the oil! The oil which meets
the
above requirements has been carefully prepared and can provide
enough lubrication action to the engine and clutch.
○Although the oil with the viscosity of 10W-
50 is recommended for
most cases, the corresponding change is also needed according to
the atmospheric conditions of the specific using areas.
2-58
