Others
Adding Lubricant to Frame Parts
●The rust must be removed with rust remover before any parts are
lubricated and the grease, oil, stain or dirt shall be removed.
●Lubricate the following positions with the specified lubricant.
Remark
○If the motorcycles are used in humid environment or on rainy days,
especially when the motorcycles are sprayed and washed with
high-pressure water,
the relevant parts must be lubricated in
accordance with the following specifications.
Fulcrum shaft: lubricated with grease
Brake handle
Brake pedal
Clutch handle
Pump connecting pin on rear brake
Side stand
Thread: lubricated with grease
Throttle cable steel cable end [A]
Cable: lubricated with rust inhibitor
Throttle cable steel cable
●Inject the rust inhibitor between cable and jacket to lubricate the
cable.
○The sprinkling lubricant on the market can be bought and used for
throttle cable steel cable.
