No. Parts and specification
Torque
Remark
N·m kgf·m
1 Frame assembly
2 Bolt M8×35 25 2.5 S
3
Left upper hanging plate component of engine
4
Nut M10×1.25
50
5.0
AL, S
5 Clip component
6
Nut M10×1.25
45
4.5
7
Allen bolt M10×40
45
4.5
S
8 Front left fixing bracket component of engine
9 Side stand assembly
10 Side stand spring
11 Allen bolt M6×16 10 1.0
12 Engine stop switch installing plate component
13 Screw M6×10 10 1.0
14 Side stand mounting bolt 50 5.0
15 Frame sign
|6
Sign rivet 3×6
17
Front right fixing bracket component of engine
18 Bolt M10×1.25×170 50 5.0 AL, S
19 Bolt M10×1.25×130 50 5.0 AL, S
20 Bolt M10×50 50 5.0 AL, S
21 Right upper hanging plate component of engine
22 Bolt M6×16 10 1.0
23 Storage battery strap component
24
Bolt M6×12
1.0
25 Storage battery bracket component
26
Fuel tank installing pad
27
Combination screw M6×16
10
1.0
28 Tool box
29 Bolt M6×25 10 1.0
30 Screw M6×25 10 1.0
31 Seat steel cable component
32 Rear fender bracket assembly
AL: tighten the fastening bolt twice alternately in accordance with the higher locking torque.
G: apply grease.
L: apply Loctite.
R: replace parts.
S: obey the specified tightening order.
