BERTHOLD TECHNOLOGIES LB4710-080 - Super-Sens detector

Chapter 13 Technical Data
Mini-Switch LB 471
107
Storage
temperature
-40 ... +70 °C
Cable bushing
M16 for cable diameter: 5 ... 8 mm
See user manual LB 4700, ID no. 56926BA1
(English: ID no. 56926BA2)
LB 4430.. with EEx
LB 5430.. without
EEx
Scintillation counter with plastic scintillator
150/150
Temperature stability: ≤0,5%
ATEX protection
types
II 2G EEx ib d IIC T6
II 2G EEx de IIC T6
Protection type
IP 65
Dose rate for 1000
I*s
-1
Cs-137
Co-60
0.14µSv
0.20µSv
FM protection type
(Option)
Class I Division 1 Group A,B,C,D
Class II Division 1 Group E,F,G
Temp. Class T6 (85° C)
Case
Stainless steel
Weight
54 kg Ex variant
52 kg not-Ex variant
Operating
temperature
-20 ... +50 °C
Detectors also available with optional
integrated water cooling.
Storage
temperature
-40 ... +55 °C
Cable bushing
M16 for cable diameter: 5 ... 8 mm
Installation flange
ND 200, NP6, DIN 2527
NaI detector LB 4700
Super-Sens detector
