Chapter 15 Technical Drawings
Mini-Switch LB 471
131
15.4 Point Source Shielding LB 744X
LB 7440 / 7442 / 7445 / 7446
1
2
3
4
5
6
Point sources
Radiation exit
Lock
Position Open
Position Closed
Type label
LB 7444
Type
Stainless
steel
case
A
B
C
D
E
FØ
G
H
J
KØ
L
M
flange
kg
LB 7440 F CR
LB 7445 F CR
-
180
142
60
60
15
18
20
173
238
200
M 8
12
ND 125,
PN 6
16°
31
LB 7440 FE CR
LB 7445 FE CR
X
X
LB 7442 F CR
LB 7446 F CR
-
240
198
110
80
20
18
20
242
306
280
M10
14
ND 200,
PN 6
9°
81
LB 7442 FE CR
X
LB 7444 CR
-
ND 200,
PN 6
6°
170
Angle of reflected beam of shielding
