BERTHOLD TECHNOLOGIES LB4710-080 - Fastening Clamps

Chapter 15 Technical Drawings
Mini-Switch LB 471
123
15.2.1 Fastening Clamps
Fastening clamps are used for the assembly of GM detectors and NaI detectors.
For detector without water cooling
D = 75
For detector with water cooling
D = 90
ID-NO 31346 (1 set= 2 clamps)
ID-NO 31347 (1 set = 2 clamps)
