4.3 Basic Setting for Standard Mode
For basic setting you have to set or check at least the sic grey
shaded parameters in the code table:
Code
no.
Designation
Value range
Factory
setting
Page
00
Password
0000 - 9999
21
01
Year
1970 - 2099
Current year
21
02
Month / Day
01.01 - 12.31
Current date
21
04
Operation mode
Standard/Professional
0 - 1
0
22
05
Detector code
0 - 99
0 or 99
22
06
Nuclide
0 - 1
0
22
10
Reading in % averaged
-999 - 9999
Reading
25
11
Reading in cps
averaged
0 - 999.9
Reading
25
16
Max. or min. limit
value switch
0 – 1
0
27
20
Empty count rate
0 - 999.9
Reading
36
21
Full count rate
0 - 999.9
Reading
22
Zero count rate
0 - 9.999
Reading
32
32
Zero count rate
0 - 9.999
Depending on
detector code
32
39
Half-value layers
1-9
2
37
50
Limit switch software
1.00 - 9.99
Version
41
51
Detector software
(only FSK detector)
1.00 - 9.99
Reading
43
52
Detector temperature °C
(only FSK detector)
-40 – 80
Reading
41
53
Detector high voltage
(only FSK detector)
500 - 1300
-1
43
54
Detector HV-default
(only FSK detector)
500 - 1300
Set in factory
44
The parameter setting requires that you are already familiar with
the basics of operation (see page 9).
To read in the zero count rate correctly, the source should not yet
be mounted when working with the Super-Sens (see page 32).
The following parameters have to be checked or set. See chapter
3.4 for a detailed description of the parameters.
Note!
The illustrations contain example values which you have to substi-
tute by actual or suitable values.
Table 7
Basic setting for
standard mode
