Chapter 3 Parameters
Mini-Switch LB 471
Reaction of the alarm relay in case of error
Define reaction of alarm relay in case of error
(Only in the professional mode)
Reaction of alarm relay in case of error
Alarm relay holds the last status
Alarm relay follows the error relay
You have to define if the alarm relay should follow the error relay
in case of error.
Reading (%)
Live reading in % level
The reading is dependent on the count rate in code 11 and the
measuring range in code 20 and 21, corresponding to 0 to 100%.
The averaging of the reading is dependent on the time constant in
code 12.
To be able to jump quickly to code 10 it suffices if you keep the
Clear button pushed down for 2 seconds. Prerequisite is that you
are not in the edit mode and that code 10 is the standard result
display. The standard result display is set in code 15.
Reading (cps)
Live reading in counts per second
The averaging of this count rate is dependent on the time constant
in code 12.
Time constant (s)
Time constant for reading averaging
(Only in the professional mode)
If you enter -01.0 (factory setting), the time constant is aver-
aged automatically. The time constant is continuously adapted to
the source decay and is set optimally.
For further explanations see page 66.
A fixed value will be accepted only if the input is equal or greater
than the automatically determined time constant.
The dot in the displayed result is a decimal point which separates
seconds from tenths of a second.
