Chapter 2 Operation
Mini-Switch LB 471
11
2.1.4 Count Rate Display
Count rates are displayed in the bottom row. For count rates of
10000 cps and higher a thousands separator is enabled. Thus, it is
possible to display count rates >9999 cps on a four-digit display.
The digits after the dot are irrelevant for a limit switch.
Count rate
Presentation of count rates
on the display
123 cps
0123
1234 cps
1234
12345 cps
12.34
123456 cps
123.4
2.1.5 Select Parameters
Push the arrow keys / to select the parameters one after the
other.
Most parameter values can be edited. Parameters which only indi-
cate readings cannot be changed (e.g.: result display in code 10).
2.1.6 Edit Mode
To edit the value of a parameter, you have to go to the edit mode.
The edit mode is enabled if you push the "Enter" button, provided
you have selected a parameter that can be edited. In the edit
mode the digit that can be edited is displayed as a flashing digit.
 In the edit mode you can change the value of the digit with the
arrow keys / .
 Push the arrow keys / you can select the next digit.
 Push the Clear button to reset the value to „0“.
 Push the Enter button also to exit the edit mode. The last value
displayed will be saved.
 To exit the edit mode without changing a value, you have to
push the Clear button a second time.
Note!
Entries outside the permissible value range are not accepted. If
values are entered incorrectly, the following warning message will
be displayed in the top row: „!!“.
