Chapter 4 Instrument Description
Mini-Switch LB 471
43
4.3.3 Super-Sens Detector
The Super-Sens detector is extremely sensitive to Gamma radia-
tion. The high sensitivity is achieved by using a 150x150 mm large
plastic scintillator. It is provided with a lead shielding to reduce the
zero count rate and to reduce interferences. Working with the Su-
per-Sens detector allows you to reduce the required source activity
significantly.
Standard Gas Ex: EEx de
LB 4430-04-0a-Gd-E
axial irradiation
LB 4430-14-0a-Gd-E
with WC, axial irradiation
LB 4431-04-0s-Gd-E
lateral irradiation. 90°
LB 4431-04-0r-Gd- E
lateral irradiation. 66°
LB 4431-14-0s-Gd-E
with WC, lateral irradiation 90°
LB 4431-14-0r-Gd-E
with WC, lateral irradiation 66°
Intrinsically safe, Gas Ex: EEx ib
LB 4430-04-0a-Gi-E
axial irradiation.
LB 4430-14-0a-Gi-E
with WC, axial irradiation
LB 4431-04-0s-Gi-E
lateral irradiation 90°
LB 4431-04-0r-Gi-E
lateral irradiation 66°
LB 4431-14-0s-Gi-E
with WC, lateral irradiation 90°
LB 4431-14-0r-Gi-E
with WC, lateral irradiation 66°
Firedamp protection
LB 4430-04-1a-Md-E
axial irradiation
LB 4431-04-1s-Md-E
lateral irradiation 90°
Firedamp protection: intrinsically safe
LB 4430-04-1a-Mi-E
axial irradiation
LB 4431-04-1s-Mi-E
lateral irradiation 90°
not Ex
LB 5430
axial irradiation
LB 5431
lateral irradiation 66°
WC = water cooling
Super-Sens
detector types
